After loading the packages, we create a function called build_qa_chain() that walks through all the necessary steps:

1. Loading the PDF: Load your PDF into the pdf-chatbot directory we created earlier. The code uses PyPDFLoader(pdf_path) to read the PDF, and we're skipping the title page since it only contains an image without text.

Make sure your PDF contains actual text, not just images. This loader is provided by LangChain to read files and convert them into document objects that LangChain can work with.

In Python, lists start at index 0, so [1:] skips the first page.

2. Chunking: Next, we split the text into smaller pieces so we can store individual sections in the vector database.

The CharacterTextSplitter() divides the entire PDF text into overlapping chunks. In this example, each chunk is 500 characters long with a 100-character overlap between consecutive chunks. These chunks are stored in the docs variable.

Why is this necessary?

Language models like Mistral or GPT can't process massive texts all at once. Imagine trying to feed a 50-page PDF in one go. By breaking the text into smaller chunks with some overlap, we ensure that important context at chunk boundaries isn't lost.

3. Embeddings: We create embeddings using HuggingFaceEmbeddings(model_name='...').

What are embeddings? They're mathematical representations of text as vectors. Once text is converted into embeddings, an AI model can compare which texts are similar—for example, which chunks best match a user's question.

With LangChain, we use the HuggingFaceEmbeddings class and the all-MiniLM-L6-v2 model from HuggingFace, which works well for this project.

4. Vector Database: We create a FAISS vector database with FAISS.from_documents(docs, embeddings).

The database automatically converts each chunk into an FAISS entry using embeddings, then we extract a retriever from it.

What is FAISS?

FAISS (Facebook AI Similarity Search) is a vector database from Facebook that stores text chunks based on their embeddings from the previous step. This allows the system to quickly find similar text passages when we ask a question. The impressive part? With LangChain, we only need a single line of code to set this up.

What is a retriever?

A retriever connects the user's question to the vector data. When we ask a question, the system converts it into a vector and searches the FAISS database for the most similar chunks. These similar chunks are likely the most relevant text sections for our question.

However, the retriever doesn't create the complete answer on its own it only returns the relevant text chunks that probably contain the answer. Think of it as the research department. Using a retriever also reduces hallucinations from the LLM because it works with a specific selection from the PDF rather than generating answers from memory.

5. Large Language Model: The LLM takes the chunks provided by the retriever and generates a response in natural language. This is the basic principle of RAG.

In the llm line, we specify that we want to use the Mistral model, which Ollama is running locally. This is why we entered the command ollama run mistral in a separate terminal during the setup steps.

What is Ollama?

Ollama is a tool that makes it easy to run LLMs locally on our own computer. It doesn't require complex setup, API keys, or cloud providers. Ollama runs in the background and provides an API that LangChain can access directly - No API key needed.

In our project, we use Ollama to run Mistral locally. This means we don't need a connection to the cloud (like OpenAI or Hugging Face), we have no API costs, and the model runs without a GPU directly on the CPU. With just a single line of code, we can integrate Ollama into LangChain. This makes it perfect for a small PDF RAG project like this that runs directly on a laptop.

6. Conversational Retrieval Chain: With ConversationalRetrievalChain, we combine the language model (Mistral) with the retriever (from FAISS) into a question-answer chain.

7. Answer as the result: At the end, we return the finished chain with return qa_chain, which we can use in chatbot_terminal.py or streamlit.py.

The model stays the same, but it gets access to an external knowledge source (in this project, a specific PDF), which reduces hallucinations.

3. File 2: streamlit_app.py

With this file, we create the graphical user interface (GUI) for the PDF chatbot. To keep things simple, we'll use a basic setup:

# streamlit_app.py: Simple web-based user interface for the PDF chatbot using Streamlit

# The UI allows users to ask questions about a PDF document and get answers generated by a local LLM (via Ollama) - combined with RAG.

import streamlit as st

from chatbot_core import build_qa_chain #Imports the function that builds the RAG pipeline.

st.set_page_config(page_title="📄 PDF-Chatbot", layout="wide") #To set up the Sreamlit page with a title & wide layout

st.title("📄 Chat with your PDF")

qa_chain = build_qa_chain("example.pdf") #Builds the QA chain using the specified PDF file

#Initializes the chat history in Streamlit's session state

if "chat_history" not in st.session_state:

st.session_state.chat_history = []

# Creates a text input field for the user to ask a question

question = st.text_input("What would you like to know?", key="input")

#If a question is submitted, the question is sent to the QA chain & stores the result

if question:

result = qa_chain({

"question": question,

"chat_history": st.session_state.chat_history

})

st.session_state.chat_history.append((question, result["answer"])) #Saves the question & the answer to the session history

# Displays the chat history in reverse order (newest on top)

for i, (q, a) in enumerate(st.session_state.chat_history[::-1]):

st.markdown(f"**❓ Question {len(st.session_state.chat_history) - i}:** {q}")

st.markdown(f"**🤖 Answer:** {a}")
